ABB Communication Module CI867K01 3BSE043660R1

Product Overview

ABB CI867K01 3BSE043660R1 is a high-performance communication interface module designed for industrial automation systems and supporting multi-protocol communication and complex network integration. It serves as a central communication hub for control systems and is widely used in areas such as electricity, petrochemical, water treatment and smart manufacturing.

Technical Specifications

Processor: Built-in special communication processor supporting high-speed data analysis and protocol conversion.

Memory: 128 MB of RAM.

Power requirements: 24 V DC (±20%), power consumption 8 W (typical value).

Working conditions:

Temperature: from -25°C to +70°C.

Protection class: IP20.

Anti-interference capability: meets IEC 61000 — 4 standard (EMC interference class: industrial level).

Communication interface:

2 Ethernet ports (10/100/1000 Mbit/s) with support for RJ45 or fiber optic (SFP module optional).

2 serial interfaces (RS232 / RS485), isolation design, support Modbus RTU, DNP3.0 and other protocols.

Protocol support:

Industrial Agreements: PROFIBUS DP, Modbus TCP/RTU, IEC 60870 — 5 — 104, OPC UA.

Electrical protocols: IEC 61850 (GOOSE/SV), DNP3.0 (for SCADA integration).

redundancy protocol: PRP/HSR (seamless redundancy network).

Enhanced capabilities:

Supports operation with controllers (e.g. PM864AK01) and other I/O modules via the AC 800M rear bus.

Can handle up to 16 parallel communication connections, supporting a hybrid with multiple main stations/stations.

Efficiency and Reliability:

Supported redundancy of communication channels (thermal preparation for dual network), switching time < 50 ms.

MTBF (Average Time Without Failure) > 150,000 hours, corresponding to IEC 61131-2.

Functional characteristics

Multiprotocol communication and gateways:

Protocol Conversion: Implementation of data display and conversion between different protocols (e.g., switching Modbus RTU to OPC UA) to remove barriers to communication between devices.

Data routing: seamless transfer of data from field devices (e.g., sensors, PLCs) to DCS, SCADA, or cloud platforms.

Real-time data exchange:

Rapid response: Support IEC 61850 GOOSE message transmission (delay < 4 ms) for power system protection.

Data Cache: The built-in buffer zone responds to network instability and ensures that key data is not lost.

Network Reservation and Security:

redundant networks: zero switching time using PRP/HSR protocol ensures high availability of communication channels.

Security mechanisms: VPN support, firewall rules, and user rights management (according to IEC 62443 cybersecurity standard).

Diagnosis and protection:

Real-time monitoring: View messages, traffic, and failure logs using LED indicators or software tools such as Control Builder.

Self-diagnosis: automatic detection of faulty lines, protocol inconsistencies, overloads and other anomalies, alarm triggering and work log recording.

Flexible configuration:

Settings: Configure protocol settings, data point tables, and communication cycles with ABB Control Builder software.

Firmware Update: Online support — Firmware updates to extend new features or fix vulnerabilities without downtime.

Application scenario

Electrical system:

Intelligent substation: as an IEC 61850 communication gateway connecting protective devices (e.g. REG670) to a monitoring system.

New power station: integration of wind/photovoltaic inverter data (Modbus TCP) into the central control system.

Process industry:

Oil refining: integration of third-party PLCs (e.g. Siemens S7) and ABB DCS (800xA system) for data exchange.

Water treatment facility: connect field instruments via Profibus DP and upload data to the cloud analytics platform.

Smart Manufacturing:

Factory Internet of Things (IIoT): Moving production device data to MES/ERP via OPC UA.

Robot management: as a communication node, coordinates the collaboration of multi-brand robots (e.g. ABB, FANACO).

Transport and infrastructure:

Tunnel monitoring system: integration of lighting data, ventilation equipment (Modbus RTU) to achieve remote centralized control.

Smart buildings: connection to the HVAC system via the BACnet protocol to optimize energy management.

Advantage

Full protocol coverage: support 30+ industrial protocols adapted to the complex isomeric network environment.

Height
