DEIF DCP2-2420 (24V/20A battery charger)
DCP2-2420 is a Danish DEIF (Danish Control) DCP2 series industrial grade 24V battery charger/DC power supply. It adopts high-frequency switching technology, low ripple, high efficiency, and wide input, designed specifically for industrial lead-acid battery float charging/equalization charging and key load power supply.

1、 Basic Information
Model: DCP2-2420
Brand: DEIF (Dankong, Denmark)
Type: 24V battery charger/stabilized DC power supply
Output: 24VDC/20A/480W
Input: 115/230VAC single-phase or 3 × 400VAC three-phase (47-63Hz)
Installation: Standard DIN rail
Weight: Approximately 1.8kg
Certification: CE, UL (optional)
2、 Core parameters
1) Electrical characteristics
Output voltage: 23-28VDC adjustable (float charge ≈ 27.2V, average charge ≈ 28.2V)
Output current: 20A continuous, peak value 25A
Ripple noise:<50mVpp (extremely low ripple, suitable for sensitive loads)
Efficiency: ≥ 92% (energy-saving, low heat generation)
Voltage stabilization accuracy: ± 0.5% (full load)
Battery compatibility: 24V Sealed Lead Acid (VRLA), Colloidal, Rich Liquid Battery
2) Protection function (full protection)
Short circuit protection: continuous short circuit automatic current limiting, fault removal automatic recovery
Overcurrent protection: 25A current limit, hiccup mode protection
Overvoltage protection: Automatic shutdown when output>30VDC
Overheating protection: power reduction at>85 ℃, shutdown at>95 ℃; Automatic recovery of temperature drop
Reverse polarity protection: The battery is not damaged by reverse connection, and there is no reverse current
No load protection: Long term no load without damage
3) Environment and Machinery
Working temperature: -20 ℃~+60 ℃ (full power); +60~+70 ℃ derating
Storage temperature: -40 ℃ to+85 ℃
Protection level: IP30 (dustproof, finger proof)
Dimensions (length x width x height): 255 x 125 x 75mm
Heat dissipation: Natural air cooling, no fan required (no noise, no maintenance)
3、 Key functions
Automatic adaptation of charging mode
Float charging: The battery maintains 27.2VDC when fully charged, preventing overcharging and extending its lifespan
Boost: When the battery is depleted, it automatically boosts to 28.2VDC and quickly recharges
Automatic switching: intelligently switches based on battery voltage, without the need for manual intervention
Dual purpose design (charger+power supply)
Can charge the battery separately
Parallel connected batteries with load (seamless battery switching for power supply in case of power failure)
Can be used independently as a 24V regulated power supply (without battery)
LED status indication
Green: Power supply normal, output ready
Yellow: Charging in progress (evenly charged)
Red: Fault (overvoltage/overheating/short circuit)
Parallel redundancy (optional)
Multiple DCP2-2420 can operate in parallel, with equal current output, improving reliability and power
4、 Typical applications
Generator set: 24V starting battery float charging/equalization charging (DEIF original matching)
Industrial control cabinet: PLC, relay, sensor 24V power supply+backup battery
Ship/offshore platform: 24V DC system, backup power supply for navigation/communication equipment
Emergency power supply (UPS): lead-acid battery pack charging+DC bus voltage stabilization
Railway/Rail Transit: Vehicle mounted 24V battery charging and control power supply
5、 Model analysis
DCP2: Series Number (Second Generation 24V Charger)
24: Output voltage 24V
20: Output current 20A
6、 Comparison with the same series
table
Model output input applicable scenarios
DCP2-2420 24V/20A 115/230VAC or 3 × 400VAC universal, small and medium-sized loads
DCP2-2440 24V/40A 3 × 400VAC (three-phase only) large load, parallel redundancy
