Emerson SE5009 power module
1、 Basic Product Information
Source of project parameters
Product model SE5009
Complete model KJ1501X1-BK1
Product series S-series system power supplies
Product type DC-DC power module
Manufacturer Emerson Process Management
Application Fields: DeltaV Automation System
Origin: United States

oplus_10485760

2、 Core functional characteristics
Source of Function Description
Power conversion converts the input 24V DC power supply into the required 12V DC and 5V DC power supplies for the system
The system power supply provides stable power for electronic devices such as controllers and I/O cards
Power redundancy can be combined with other SE5009 modules to form a redundant power system, improving system reliability
Overcurrent protection has overcurrent protection function to prevent equipment damage
The installation method is directly installed on the 2-width power supply/controller carrier on the left side of the controller
Efficient, reliable, efficient, high reliability, easy to install
3、 Technical specifications and parameters
Source of parameter values
Input voltage 24V DC (Bulk 24VDC)
Output voltage 1 5V DC (for adjacent controllers)
Output voltage 2 12V DC (for I/O card)
Protection functions include overvoltage protection, overcurrent protection, and short circuit protection
Install the 2-width power supply/controller carrier on the left side of the position controller
System type DeltaV digital automation system
4、 SE5009 series model comparison
Model Type Channel Number/Function Description
SE5009 DC-DC power supply 1 channel 24V DC to 12V/5V DC
VE5001 AC/DC Power Supply — AC/DC System Power Supply
VE5008 Dual DC/DC Power Supply — System Dual DC Power Supply
VE5009 24/12V Enhanced System Power Supply -24/12V DC Enhanced System Power Supply
VE5010 I/O Module Power Carrier — I/O Module Power Carrier
VE5011 DIN Rail AC/DC Power Supply — DIN Rail Installation AC/DC Power Supply
VE5012 DIN Rail AC/DC Power Supply — DIN Rail Installation AC/DC Power Supply
SE4009 S series power supply — S series power module

oplus_10485760

5、 DeltaV system compatibility module
Module category compatible model
Controllers VE5009, VE5001, VE5008, VE5011, VE5012
I/O modules VE4003S7B1, VE4001S2T1B1, VE4011B1/B2
Intelligent Logic Solver VS3202 (SLS 1508)
Communication modules VE6006, VE6019, VE6048
Redundant module VE5134 (active redundant module)
6、 Application Fields
Industry application scenarios
Petrochemical process control system, DCS system
Automation control of power plants
Natural gas transportation and processing control
Pharmaceutical production automation system
Process Control in Manufacturing Industry
7、 Important Notice
1. Model confirmation
SE5009=Power module (DC-DC 24V to 12V/5V)
VE5009=Controller module (24/12V enhanced system power supply)
⚠️ Note: SE5009 and VE5009 are two different products! SE5009 is a power module, VE5009 is a controller/enhanced power module

2. System compatibility
SE5009 needs to be used in conjunction with the DeltaV system controller
Installation position: 2-width power supply/controller carrier on the left side of the controller
3. Protection function
Input Overvoltage Protection
Output overvoltage protection
Output current limit protection
Output short circuit protection
4. Reference for alternative models
Recommended models for functions
AC/DC power supply VE5001 (KJ1501X1-BA2)
Dual DC power supply VE5008 (KJ1501X1-BC1/BC2)
24/12V power supply VE5009
I/O power supply carrier VE5010
5. Official technical support
Suggest consulting the official technical manual of Emerson Process Management for complete specifications
Contact Emerson DeltaV authorized dealers for technical support
Related DeltaV controller module reference
Model type description
VE5009 Enhanced System Power Supply 24/12V DC System Power Supply
VE3008 Redundant Controller System Redundant Controller
VE5001 AC/DC power supply system power supply
VE5008 Dual DC/DC Power Supply System Dual DC Power Supply
