GE DS200ADGIH1AAA Control Interface Board

product overview

The GE DS200ADGIH1AAA is an auxiliary interface board designed specifically for GE Mark V series control systems, providing additional input/output interfaces and functional extensions. It can connect external devices such as sensors, actuators, etc., thereby expanding the functionality and flexibility of the system.

technical specifications

Number of input channels: 16 analog inputs.

Number of output channels: 8 analog outputs.

Input signal types: voltage (-10V~+10V), current (4~20mA), thermocouple (K/J/T type) RTD（PT100/PT1000）。

Output signal type: voltage, current.

Resolution: 16 bits.

Sampling frequency: up to 100kHz.

Accuracy: ± 0.1%.

Response time: ≤ 1ms.

Communication Protocol: Supports various industrial communication protocols such as Modbus TCP/IP, EtherCAT, Profinet, etc.

Interface type: RJ45, fiber optic interface.

Working temperature: -20 ℃~70 ℃.

Working humidity: 5%~95% (no condensation).

Protection level: IP20.

Power parameters: Input voltage 24VDC, maximum input current 2A.

Size: 200mm x 150mm x 100mm.

Weight: 1.1kg.

Functional Features

High speed processing capability: Adopting advanced digital signal processing technology, it has high-speed processing capability and signal acquisition capability.

High precision control: Control accuracy up to ± 0.1%, ensuring stable operation of industrial equipment.

Rich communication interfaces: Supports multiple industrial communication protocols, facilitating data exchange and remote monitoring with other devices.

Wide temperature working range: capable of stable operation within the temperature range of -20 ℃~70 ℃, suitable for various harsh environments.

Compact design: small size, light weight, easy to install and maintain.

Flexible configuration: Provides multiple analog and digital input/output interfaces, making it convenient for users to configure and expand according to their actual needs.

application area

Power industry: used for monitoring and protection systems in power plants.

Petrochemical industry: Process control systems used in refineries and chemical plants.

Metallurgical industry: used for automation control systems in steel plants and non-ferrous metal plants.

Automation control systems for other industrial fields such as water treatment, building materials, food processing, etc.

precautions

Installation environment: Ensure that the module is installed in a dust-free, dry, and well ventilated environment, avoiding high temperatures, high humidity, or corrosive gases.

Electrical connection: Connect power and signal lines correctly to avoid module damage or performance degradation caused by wiring errors.
