GE IS220PDIOH1A Control Module

####Product Overview
GE IS220PDIOH1A is a high-performance discrete input/output module designed specifically for GE Mark VIe series distributed control systems. It provides electrical connections for processing input and output of discrete signals.
####Functional Features
-* * Input/Output Function * *:
-Supports up to 24 contact inputs and 12 relay outputs.
-Receive feedback signals specific to the terminal board.
-Ethernet connection:
-Supports electrical connections between one or two I/O Ethernet networks and discrete input/output terminal boards.
-Equipped with two RJ45 Ethernet connectors.
-* * High performance processor * *:
-Share a processor board with fast CPU, flash memory, and RAM.
-Support hardware reset circuit and watchdog timer to ensure stable system operation.
-* * LED indicator light * *:
-Equipped with LED indicator lights for displaying visual diagnostic information, making it convenient for users to quickly understand the working status of the module.
-* * High reliability * *:
-Adopting redundant design to ensure the reliable operation of the system.
-Capable of optical isolation up to 1500V input isolation, improving the system’s anti-interference ability.
-Wide working temperature range:
-The working temperature range is from 0 ° C to 60 ° C.

####Technical specifications
-* * Input channel * *: 24 digital inputs (DI) and 12 C-type inputs.
-* * Output channel * *: 12 relay outputs.
-* * Analog inputs * *: 8, supporting 4-20mA or 0-10V.
-* * Analog output * *: 8, supporting 4-20mA or 0-10V.
-Accuracy: 0.1%.
-* * Resolution * *: 16 bits.
-* * Power Supply * *: Dual power redundant input, DC(9-36)V， Typical DC24V, power consumption less than 4W.
-* * Communication interface * *: Dual 100MB full duplex Ethernet ports.
-* * Dimensions * *: 132mm × 105mm × 52mm (height × depth × width).
-Protection level: IP30.

####Application Fields
-* * Turbine control system * *:
-As an important component of the Mark VI series turbine control system, it is widely used in power plants with gas and steam turbines.
-Ensure accurate data collection and transmission to improve the reliability and efficiency of the turbine control system.
-Industrial Automation:
-Suitable for various industrial automation control systems, such as production line control, process control, etc.
-Provide stable input/output functions to meet the needs of industrial automation systems.

####Installation and operation
-* * Installation * *:
-Insert one PDIO I/O pack for simple applications, or insert three PDIO I/O packs for Triple Modular Redundancy (TMR) applications.
-Use terminal board connectors to mechanically secure the package and ensure that there is no right angle force between the connectors.
-* * Operation * *:
-High performance processors support fast data processing and transmission.
-The system manages the current surge during power input through a soft start circuit.
